HATS-10 b (Exoplanet, Candidate)

RA: 19h 37m 13.64s, DE: -22° 16' 16.10" (294.3068333233, -22.2711388882)

Data:
  • Brightness (Mag): 13.200
  • Transit depth (%): 1
  • Transit depth (Mag): 0.0108
  • Transit duration (m): 180.42
  • Planet radius (RJup): 0.969 +/- 0.061
  • Star radius (RSun): 1.105 +/- 0.055
  • Impact factor: 0.34 +/- 0.11
  • Created by: admin
  • Reference:
    Bonomo et al. 2017
Show list of observations >>
Orbital elements:
  • Period (d): 3.312846
  • Epoch (JD): 2456457.88271
  • Semimajor axis (AU): 0.04493 +/- 0.00076
  • Inclination (°): 87.79 +/- 0.72
Chart
HATS-10
Source: The STScI Digitized Sky Survey
Number of transits

3 x

Number of observers

2 x

Last observed before

25 days

Transit-timing variations (TTV diagram)
Times of mid-transit
M = 2456457.88271 + 3.312846 * E
ID HJDmid UTCmid Epoch O-C (d) Duration (min) Depth (mmag) Phot. band DQ Light curve Observer & Reference Note
Transit depth variations
Transit duration variations
