TOI-2236 b (Exoplanet, Confirmed)

RA: 01h 20m 39.84s, DE: -86° 58' 47.87" (20.1659999950, -86.9799638882)

Data:
  • Brightness (Mag): 11.600
  • Transit depth (%): 0.7011
  • Transit depth (Mag): 0.00759
  • Transit duration (m): 182.88
  • Planet radius (RJup): 1.282 +/- 0.032
  • Star radius (RSun): 1.573 +/- 0.033
  • Impact factor: 0.766 +/- 0.014
  • Created by: admin
Show list of observations >>
Orbital elements:
  • Period (d): 3.5315902
  • Epoch (JD): 2459011.45704
  • Semimajor axis (AU): 0.05009 +/- 0.00082
  • Inclination (°): 83.58 +/- 0.26
Chart
TOI-2236
Source: The STScI Digitized Sky Survey
Number of transits

5 x

Number of observers

2 x

Last observed before

1 days

Transit-timing variations (TTV diagram)
Times of mid-transit
M = 2459011.45704 + 3.5315902 * E
ID HJDmid UTCmid Epoch O-C (d) Duration (min) Depth (mmag) Phot. band DQ Light curve Observer & Reference Note
Transit depth variations
Transit duration variations
Comments

Timeline
