WASP-70A b (Exoplanet, Confirmed)

RA: 21h 01m 54.48s, DE: -13° 25' 59.80" (315.4769999900, -13.4332777771)

Data:
  • Brightness (Mag): 10.790
  • Transit depth (%): 0.97
  • Transit depth (Mag): 0.01048
  • Transit duration (m): 200.02
  • Planet radius (RJup): 1.164 +/- 0.088
  • Star radius (RSun): 1.215 +/- 0.077
  • Impact factor: 0.431 +/- 0.122
  • Created by: admin
  • Reference:
    http://uk.arxiv.org/abs/1310.5654
Show list of observations >>
Orbital elements:
  • Period (d): 3.7130203
  • Epoch (JD): 2455736.50348
  • Semimajor axis (AU): 0.04853 +/- 0.00062
  • Inclination (°): 87.12 +/- 0.95
Chart
WASP-70A
Source: The STScI Digitized Sky Survey
Number of transits

5 x

Number of observers

3 x

Last observed before

2 days

Transit-timing variations (TTV diagram)
Times of mid-transit
M = 2455736.50348 + 3.7130203 * E
ID HJDmid UTCmid Epoch O-C (d) Duration (min) Depth (mmag) Phot. band DQ Light curve Observer & Reference Note
Transit depth variations
Transit duration variations
Comments

Timeline
