Kepler-17 b (Exoplanet, Candidate)

RA: 19h 53m 34.86s, DE: +47° 48' 54.00" (298.3952499950, 47.8150000000)

Data:
  • Brightness (Mag): 14.141
  • Transit depth (%): 1.98
  • Transit depth (Mag): 0.02129
  • Transit duration (m): 136.6
  • Planet radius (RJup): 1.312 +/- 0.018
  • Star radius (RSun): 1.019 +/- 0.033
  • Impact factor: 0.268 +/- 0.013
  • Created by: admin
  • Reference:
    http://arxiv.org/abs/1107.5750
http://xxx.lanl.gov/abs/1102.0541v1
Show list of observations >>
Orbital elements:
  • Period (d): 1.4857108
  • Epoch (JD): 2455185.67803
  • Semimajor axis (AU): 0.02591 +/- 0.00036
  • Inclination (°): 87.2 +/- 0.15
Chart
Kepler-17
Source: The STScI Digitized Sky Survey
Number of transits

139 x

Number of observers

30 x

Last observed before

3 days

Transit-timing variations (TTV diagram)
Times of mid-transit
M = 2455185.67803 + 1.4857108 * E
ID HJDmid UTCmid Epoch O-C (d) Duration (min) Depth (mmag) Phot. band DQ Light curve Observer & Reference Note
Transit depth variations
Transit duration variations
Comments

Timeline
