TrES-4 b (Exoplanet, Candidate)

RA: 17h 53m 13.05s, DE: +37° 12' 42.80" (268.3043749950, 37.2118888889)

Data:
  • Brightness (Mag): 11.300
  • Transit depth (%): 0.9745
  • Transit depth (Mag): 0.01053
  • Transit duration (m): 214.2
  • Planet radius (RJup): 1.706 +/- 0.056
  • Star radius (RSun): 1.798 +/- 0.052
  • Impact factor: 0.761 +/- 18
  • Created by: admin
  • Reference:
    http://arxiv.org/abs/1103.3078
Show list of observations >>
Orbital elements:
  • Period (d): 3.5539268
  • Epoch (JD): 2454230.90524
  • Semimajor axis (AU): 0.05084 +/- 0.0005
  • Inclination (°): 82.81 +/- 0.37
Chart
TrES-4
Source: The STScI Digitized Sky Survey
Number of transits

65 x

Number of observers

11 x

Last observed before

4 days

Transit-timing variations (TTV diagram)
Times of mid-transit
M = 2454230.90524 + 3.5539268 * E
ID HJDmid UTCmid Epoch O-C (d) Duration (min) Depth (mmag) Phot. band DQ Light curve Observer & Reference Note
Transit depth variations
Transit duration variations
Comments

Timeline
