TOI-3693 b (Exoplanet, Confirmed)

RA: 01h 02m 37.05s, DE: +51° 18' 14.01" (15.6543749950, 51.3038916667)

Data:
  • Brightness (Mag): 11.948
  • Transit depth (%): 2.134
  • Transit depth (Mag): 0.02293
  • Transit duration (m): 213.408
  • Planet radius (RJup): 1.124 +/- 0.029
  • Star radius (RSun): 0.791 +/- 0.017
  • Impact factor: 0.17 +/- 0.11
  • Created by: admin
  • Reference:
    Yee et al. 2022
Show list of observations >>
Orbital elements:
  • Period (d): 9.088516
  • Epoch (JD): 2458806.68164
  • Semimajor axis (AU): 0.0813 +/- 0.0012
  • Inclination (°): 89.57 +/- 0.29
Chart
TOI-3693
Source: The STScI Digitized Sky Survey
Number of transits

12 x

Number of observers

8 x

Last observed before

20 days

Transit-timing variations (TTV diagram)
Times of mid-transit
M = 2458806.68164 + 9.088516 * E
ID HJDmid UTCmid Epoch O-C (d) Duration (min) Depth (mmag) Phot. band DQ Light curve Observer & Reference Note
Transit depth variations
Transit duration variations
Comments

Timeline
