WASP-22 b (Exoplanet, Confirmed)

RA: 03h 31m 16.30s, DE: -23° 49' 10.00" (52.8179166567, -23.8194444438)

Data:
  • Brightness (Mag): 12.000
  • Transit depth (%): 1
  • Transit depth (Mag): 0.0108
  • Transit duration (m): 197.3
  • Planet radius (RJup): 1.12 +/- 0.04
  • Star radius (RSun): 1.13 +/- 0.03
  • Impact factor: 0.13 +/- 0.08
  • Created by: admin
  • Reference:
    http://arxiv.org/abs/1004.1514
ephemeris: Bonomo et al. 2017
Show list of observations >>
Orbital elements:
  • Period (d): 3.5327313
  • Epoch (JD): 2455497.40043
  • Semimajor axis (AU): 0.0468 +/- 0.0004
  • Inclination (°): 89.2 +/- 0.5
Chart
WASP-22
Source: The STScI Digitized Sky Survey
Number of transits

16 x

Number of observers

3 x

Last observed before

3 days

Transit-timing variations (TTV diagram)
Times of mid-transit
M = 2455497.40043 + 3.5327313 * E
ID HJDmid UTCmid Epoch O-C (d) Duration (min) Depth (mmag) Phot. band DQ Light curve Observer & Reference Note
Transit depth variations
Transit duration variations
Comments

Timeline
