WASP-20 b (Exoplanet, Confirmed)

RA: 00h 20m 38.53s, DE: -23° 56' 08.60" (5.1605416617, -23.9357222219)

Data:
  • Brightness (Mag): 10.680
  • Transit depth (%): 1.16
  • Transit depth (Mag): 0.01252
  • Transit duration (m): 203.9
  • Planet radius (RJup): 1.458 +/- 0.057
  • Star radius (RSun): 1.392 +/- 0.044
  • Impact factor: 0.718 +/- 0.018
  • Created by: admin
  • Reference:
    http://uk.arxiv.org/abs/1402.1482v2
Show list of observations >>
Orbital elements:
  • Period (d): 4.8996285
  • Epoch (JD): 2455715.65562
  • Semimajor axis (AU): 0.06003 +/- 0.00067
  • Inclination (°): 85.57 +/- 0.22
Chart
WASP-20
Source: The STScI Digitized Sky Survey
Number of transits

8 x

Number of observers

2 x

Last observed before

21 days

Transit-timing variations (TTV diagram)
Times of mid-transit
M = 2455715.65562 + 4.8996285 * E
ID HJDmid UTCmid Epoch O-C (d) Duration (min) Depth (mmag) Phot. band DQ Light curve Observer & Reference Note
Transit depth variations
Transit duration variations
Comments

Timeline
