WASP-55 b (Exoplanet, Confirmed)

RA: 13h 35m 01.94s, DE: -17° 30' 12.70" (203.7580833283, -17.5035277778)

Data:
  • Brightness (Mag): 11.800
  • Transit depth (%): 1.58
  • Transit depth (Mag): 0.01702
  • Transit duration (m): 211.68
  • Planet radius (RJup): 1.3 +/- 0.3
  • Star radius (RSun): 1.06 +/- 0.02
  • Impact factor: 0.15 +/- 0.12
  • Created by: admin
  • Reference:
    http://arxiv.org/abs/1204.5095
Show list of observations >>
Orbital elements:
  • Period (d): 4.465633
  • Epoch (HJD): 2455737.9396
  • Semimajor axis (AU): 0.0533 +/- 0.0007
  • Inclination (°): 89.2 +/- 0.6
Chart
WASP-55
Source: The STScI Digitized Sky Survey, FoV: 15 x 15 arcmin
Number of transits

12 x

Number of observers

3 x

Last observed before

446 days

Transit-timing variations (TTV diagram)
Times of mid-transit
M = 2455737.9396 + 4.465633 * E
ID HJDmid UTCmid Epoch O-C (d) Duration (min) Depth (mmag) Phot. band DQ Light curve Observer & Reference Note
Transit depth variations
Transit duration variations
Comments

Timeline
