TrES-5 b (Exoplanet, Candidate)

RA: 20h 20m 53.00s, DE: +59° 26' 55.00" (305.2208333283, 59.4486111108)

TrES-5 b b

Data:
  • Constellation: Cyg
  • Brightness (Mag): 13.700
  • Transit depth (%): 2
  • Transit depth (Mag): 0.0215
  • Transit duration (m): 111.312
  • Planet radius (RJup): 1.209
  • Star radius (RSun): 0.866
  • Impact factor: 0.579 +/- 0.026
  • Created by: admin
  • Reference:
    https://exoplanetarchive.ipac.caltech.edu/overview/TrES-5%20b
https://ui.adsabs.harvard.edu/abs/2023ApJS..265....4K/abstract
Show list of observations >>
Orbital elements:
  • Period (d): 1.482246865 +/- 9.3E-08
  • Epoch (HJD): 2457011.47035 +/- 8E-05
  • Semimajor axis (AU): 0.02446
  • Inclination (°): 84.529 +/- 0.005
Change log:

10/5/2026, Filip Walter:

  • Epoch error: Null → 0.00008
  • Epoch: 2456833.6008 → 2457011.47035
  • Period error: Null → 0.000000093
  • Period: 1.48224718 → 1.482246865
  • Reference: http://exoplanets.org/detail/TrES-5_b ephemerides: Kokori et al. 2021 → https://exoplanetarchive.ipac.caltech.edu/overview/TrES-5%20b https://ui.adsabs.harvard.edu/abs/2023ApJS..265....4K/abstract

Chart
TrES-5
Source: The STScI Digitized Sky Survey, FoV: 15 x 15 arcmin
Number of transits

324 x

Number of observers

43 x

Last observed before

12 days

Transit-timing variations (TTV diagram)
Times of mid-transit
M = 2457011.47035 + 1.482246865 * E
ID HJDmid UTCmid Epoch O-C (d) Duration (min) Depth (mmag) Phot. band DQ Light curve Observer & Reference Note
Transit depth variations
Transit duration variations
