Kepler-686 b (Exoplanet, Confirmed)

RA: 19h 00m 51.00s, DE: +39° 01' 39.00" (285.2125000000, 39.0274999993)

Data:
  • Brightness (Mag): 16.020
  • Transit depth (%): 1.44
  • Transit depth (Mag): 0.01552
  • Transit duration (m): 117.36
  • Planet radius (RJup): 1.084 +/- 0.176
  • Star radius (RSun): 0.92 +/- 0.149
  • Impact factor: 0.0001
  • Created by: admin
  • Reference:
    http://xxx.lanl.gov/abs/1102.0541v1
Morton et al. 2016
Gajdoš et al. 2019
Show list of observations >>
Orbital elements:
  • Period (d): 1.5947454647
  • Epoch (JD): 2455003.64837
  • Semimajor axis (AU): 0.027
  • Inclination (°): 90 +/- 1
Chart
Kepler-686
Source: The STScI Digitized Sky Survey
Number of transits

5 x

Number of observers

3 x

Last observed before

216 days

Transit-timing variations (TTV diagram)
Times of mid-transit
M = 2455003.64837 + 1.5947454647 * E
ID HJDmid UTCmid Epoch O-C (d) Duration (min) Depth (mmag) Phot. band DQ Light curve Observer & Reference Note
Transit depth variations
Transit duration variations
Comments

Timeline
