XO-3

RA: 04h 21m 52.71s, DE: +57° 49' 01.89" (65.4696250000, 57.8171916660)

9/23/2009, 3:31 AM - 9/23/2009, 8:51 AM (UTC)

Data:

  • Observer: Stan Shadick
  • Created: 9/26/2009 11:42:22 PM
  • Station: University of Saskatchewan Physics Roof Observatory
    Lat: +52°, Long: +253°
  • Instrument: Meade 10 LX200GPS, SBIG ST10XME with AO-7
  • Photometric band: R
  • Time standard: Gjd
  • Brightness in: Mag
Note:
GENERATED FROM TRANSIT id=197
Determined transits
  • 2455097.74354 (9/23/2009, 05:50)
    Tresca ID: 1253994142
    Planet designation: XO-3 b
    HJDmid: 2455097.74474 +/- 0.00178
    Heliocentric correction: 0.00120
    Transit depth (Mag): 0.00680 +/- 0.00100
    Transit duration (Min): 157.90 +/- 6.40
    Standard deviation (mmag): 5.1
    Data quality index: 4
    Data density (data/min): 1.98
    Fitting algorithm: Original ETD
    Note:
    Processed with MaxIm
    Aperture = 7 pixels
    Gap = 3 pixels
    Annulus = 6 pixels
    C1: R = 8.516
    C2: R = 10.490
