WASP-19 (Transiting exoplanet)

RA: 09h 53m 40.08s, DE: -45° 39' 33.06" (148.4169874950, -45.6591833333)

5/9/2018, 06:32 - 5/9/2018, 09:11 (UTC)

Data:
  • Observer: Carl R Knight
  • Created by: Carl Knight
  • Created: 5/10/2018, 01:03 UTC
  • Station: Ngileah Observatory
    Lat: -40°, Long: +175°
  • Instrument: 0.3m F10 SCT, SBIG ST10XE
  • Photometric band: R
  • Time standard: GJD
  • Brightness in: Mag
  • Magnitude type: Standardized
Note:
GENERATED FROM TRANSIT id=5615
Determined transits
  • 2458247.803220 (5/9/2018, 07:16 UTC)
    Tresca ID: 1525907006
    Planet designation: WASP-19 b
    HJDmid: 2458247.805270 +/- 0.000340
    Heliocentric correction: 0.002050
    Transit depth (Mag): 0.025000 +/- 0.001100
    Transit duration (Min): 93.60 +/- 1.40
    Standard deviation (mmag): 2.2
    Data quality: 1 (excellent)
    Data density (data/min): 1.41
    Fitting algorithm: Original ETD
    Note:
    Close to sunset. Started still in twilight conditions.
Actions:
Light curve
Field identification - Star field chart
Chart - WASP-19, JD 2458247.77279
Field identification - Explicitly named stars

No comparison or check stars are explicitly listed for this observation. They should be marked in the star field chart.
