NSVS 5750160 (Eclipsing binary)

RA: 20h 40m 52.38s, DE: +40° 13' 18.56" (310.2182337135, 40.2218225273)

AsasSnV: ASASSN-V J204052.39+401318.6, Gaia: Gaia DR3 2064536147203214208, Gsc: GSC 03170-00886, Nsvs: NSVS 5750160, Tic: TIC 65429477, TwoMass: 2MASS J20405237+4013185, Tyc: TYC 3170-886-1, Other: [GGM2006] 5750159, Other: G3170.00886

Data:
  • Constellation: Cyg
  • Variability type: EW
  • Maximal brightness (Mag): 11.200 (V)
  • Minimum brightness (Mag): 11.930 (V)
  • Created by: admin
Show list of observations >>
Periodic elements:
  • Period (d): 0.338515000000000
  • Epoch (HJD): 57239.43700
  • Secondary Epoch (HJD): 57239.60626
Change log:

7/7/2026, Jan Hykel:

  • Alternative designation: AsasSnV: ASASSN-V J204052.39+401318.6, Gaia: Gaia DR3 2064536147203214208, Gsc: GSC 03170-00886, Nsvs: NSVS 5750160, Tic: TIC 65429477, TwoMass: 2MASS J20405237+4013185, Tyc: TYC 3170-886-1, : [GGM2006] 5750159 → AsasSnV: ASASSN-V J204052.39+401318.6, Gaia: Gaia DR3 2064536147203214208, Gsc: GSC 03170-00886, Nsvs: NSVS 5750160, Tic: TIC 65429477, TwoMass: 2MASS J20405237+4013185, Tyc: TYC 3170-886-1, : [GGM2006] 5750159, : G3170.00886
  • Secondary Epoch: Null → 57239.6062575
  • Epoch: 2456492.85265 → 57239.437
  • Period: 0.338511 → 0.338515
  • Epoch: Null → 2456492.85265
  • Period: Null → 0.338511
  • Variability type: Null → EW
  • Photometric band: Null → V
  • Minimum brightness: Null → 11.93
  • Maximal brightness: Null → 11.2
  • Declination: 40.2216944438 → 40.2218225273
  • Right ascension: 310.21799999 → 310.21823371347
  • Alternative designation: → AsasSnV: ASASSN-V J204052.39+401318.6, Gaia: Gaia DR3 2064536147203214208, Gsc: GSC 03170-00886, Nsvs: NSVS 5750160, Tic: TIC 65429477, TwoMass: 2MASS J20405237+4013185, Tyc: TYC 3170-886-1, : [GGM2006] 5750159

Chart
NSVS 5750160
Source: The STScI Digitized Sky Survey, FoV: 15 x 15 arcmin
Number of observations

2 x

Number of observers

2 x

Last observed before

26 days

O-C diagram
Times of minima / maxima - including records from the original O-C gateway
P: M = 2457239.437 + 0.338515 * E
S: M = 2457239.60626 + 0.338515 * E
ID HJDmin Error (+/-) UTCmin Epoch O-C (d) P/S Phot. band Observer Publication Note Instrument
Phase curve
Comments

Timeline
