AZ Cam (Eclipsing binary)

RA: 09h 14m 38.44s, DE: +81° 56' 30.40" (138.6601666617, 81.9417777774)

AsasSnV: ASASSN-V J091439.00+815631.5, Gaia: Gaia DR3 1145650163630708864, Gcvs: AZ Cam, Gsc: GSC 04547-01381, Tic: TIC 415703391, TwoMass: 2MASS J09143841+8156303, Tyc: TYC 4547-1381-1, Other: AG+82 260, Other: BD+82 263, Other: BV 189, Other: PPM 1541, Other: SAO 1470

Data:
  • Constellation: Cam
  • Variability type: EA
  • Maximal brightness (Mag): 10.100 (P)
  • Minimum brightness (Mag): 10.900 (P)
  • Brightness in secondary minimum (Mag): 10.800 (P)
  • Astrophysical interest: Light time effect (LTE)
  • Created: 6/1/1996
  • Created by: admin
Show list of observations >>
Periodic elements:
  • Period (d): 1.319228000000000
  • Epoch (HJD): 40655.47920
  • Secondary Epoch (HJD): 40656.13880
Change log:

7/23/2026, Filip Walter:

  • Astrophysical interest: Nothing → Light time effect (LTE)
  • Variability type: EB → EA
  • Name: AZ → AZ Cam
  • Alternative designation: → AsasSnV: ASASSN-V J091439.00+815631.5, Gaia: Gaia DR3 1145650163630708864, Gcvs: AZ Cam, Gsc: GSC 04547-01381, Tic: TIC 415703391, TwoMass: 2MASS J09143841+8156303, Tyc: TYC 4547-1381-1, : AG+82 260, : BD+82 263, : BV 189, : PPM 1541, : SAO 1470

Chart
AZ Cam
Source: The STScI Digitized Sky Survey, FoV: 15 x 15 arcmin
Number of observations

9 x

Number of observers

6 x

Last observed before

104 days

O-C diagram
Times of minima / maxima - including records from the original O-C gateway
P: M = 2440655.4792 + 1.319228 * E
S: M = 2440656.1388 + 1.319228 * E
ID HJDmin Error (+/-) UTCmin Epoch O-C (d) P/S Phot. band Observer Publication Note Instrument
Phase curve
Comments

Timeline
